Auo 13.3 Inch Tft Lcd B133han06.3 Hw0b 1920*1080 In Stock On-Cell Touch, I²C/Usb
Product Details:
| Place of Origin: | tw |
| Brand Name: | AUO |
| Model Number: | B133han06.3 Hw0b |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Delivery Time: | 1-8weeks |
| Payment Terms: | T/T |
| Supply Ability: | 1000pcs/month |
|
Detail Information |
|||
| Display Type: | TFT | Size: | 13.3 Inch |
|---|---|---|---|
| Interface: | RGB | Resolution: | 1920(RGB)x1080 (FHD) |
| Outline Dimension: | 300.26(W)×177.55(H)×4.5(D) Mm | Active Area: | 293.76(W)×165.24(H) Mm |
| Viewing Angle: | 85/85/85/85 (Typ.)(CR≥10) | Brightness: | 300cd/m2 |
| Backlight: | WLED [16S4P] | Operating Temperature: | 20~60℃,20~60℃ |
| Response Time: | 25 (Typ.)(Tr+Tf) Ms | ||
Product Description
Here is the technical specification and product description for the E Ink display model B133han06.3 Hw0b by AU Optronics:
Technical Specification:
Model: B133han06.3 Hw0b
Size: 13.3 inches
Resolution: 1920x1080 pixels
Panel Type: IPS (In-Plane Switching)
Response Time: Fast response time (specific time depends on manufacturer specifications)
Viewing Angle: Wide viewing angle for optimal viewing from different angles
Brightness: Typically 200-300 nits (specific brightness depends on manufacturer specifications)
Contrast Ratio: Typically 1000:1 (specific contrast ratio depends on manufacturer specifications)
Color Gamut: Typically supports a wide color gamut (specific color gamut depends on manufacturer specifications)
Product Description:
The AU Optronics B133han06.3 Hw0b is a high-quality 13.3-inch E Ink display designed for various portable devices. It features an IPS panel technology that provides wide viewing angles and high color accuracy, ensuring clear and crisp images from different viewing angles. The screen has a resolution of 1920x1080 pixels, delivering detailed and sharp visuals along with clear text.
The display comes with a narrow bezel design, maximizing the screen real estate for an immersive viewing experience. It also includes a reflection protection coating, reducing glare and reflections in both indoor and outdoor environments, enhancing the visual experience and comfort.
The B133HAN06.3 HW0B (Product Code: AUO212D) is a 13.3-inch LCD module product with a-Si TFT-LCD technology from AU Optronics Corporation (AUO), which is assembled with a WLED backlight, LED Driver Backlight Driver Included, and On-Cell Touch.According to the product specification released by AUO (AUO) on Product Specification with version number Ver0.1 released on 19 April 2019, the B133HAN06.3 HW0B displays a resolution of 1920 (RGB) x 1080 (FHD), with an aspect ratio of 16:9 (W:H), and pixels are arranged in an RGB vertical bar. Its display area measures 293.76 x 165.24 (W x H) mm, exterior dimensions are 300.26 x 177.55 (W x H) x 4.5 (thickness) mm, the surface treatment is matte, and the net weight of the product is 220g (Max.) Appearance style is a thin screen (PCBA bending, thickness ≤ 3.0mm). The backlight of this product adopts WLED light-emitting side-entry light source, the service life of the light source is 15K hours, including the LED driver. B133HAN06.3 HW0B adopts eDP (2 Lanes) signal interface, a total of 40 pins, using the terminal connection, the drive screen voltage is 3.3V (Typ.). It has a typical vertical refresh rate Fv of 60Hz, an operating temperature of -20 ~ 60°C, a storage temperature of -20 ~ 60°C, and a vibration resistance of 1.5G (14.7 m/s²). This model is recommended for use in notebooks based on its features such as touchscreen, white LED backlight, LED driver included, terminal flip-flop, matte surface, eDP1.3.
